• 4-speakers
• Aux 12V pwr outlet
• Cargo tie down loops
• Cigar lighter
• Cloth high-back front bucket seats
• Courtesy & underhood lamps
• Fixed antenna
• Folding rear seat
• Front seat area carpeting
• Full-length floor console
• Glove box w/lock
• Leather wrapped steering wheel
• Rear seat/cargo area carpeting
• Sport bar w/full padding
• Tilt steering column
• Tip & slide passenger seat

• (5) 16" x 8" "Moab" aluminum wheels
• 117-amp alternator
• 19 gallon fuel tank
• 4-wheel pwr disc brakes
• 4.11 axle ratio
• 4:1 Rocktrac HD part time 4WD system
• 500-CCA maintenance free battery
• Front/rear stabilizer bars
• Full size spare tire w/outside carrier
• HD Dana 44/226MM rear axle
• HD Dana M44/216MM front axle
• High pressure gas-charged shock absorbers
• LT245/75R16 BSW on/off road
• Pwr recirculating ball steering
• Skid plates-inc: transfer case, fuel tank
• Tethered gas cap
• Truelok differential

• Driver & front passenger next generation airbags

4.0L (242) SMFI I6 "POWER TECH" ENGINE

• (STD)

• Cloth Seats
• Adjustable Steering Wheel
• Fog Lamps
• Variable Speed Intermittent Wipers
• Power Outlet

• Vehicle
• EPA Classification: 4WD Sport Utility Vehicles
• Mileage
• EPA Fuel Economy Est - City (MPG): 15
• EPA Fuel Economy Est - Hwy (MPG): 18
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 500
• Maximum Alternator Capacity (amps): 117
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Base Curb Weight (lbs): 3716
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): - TBD -
• Wt Distributing Hitch - Max Tongue Wt. (lbs): - TBD -
• Suspension
• Suspension Type - Front: Solid Axle
• Suspension Type - Rear: Trailing Arms
• Suspension Type - Front (Cont.): w/Coil Springs
• Suspension Type - Rear (Cont.): w/Coil Springs
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.0 x 0.94
• Rear Brake Rotor Diam x Thickness (in): 11.2 x 0.47
• Tires
• Front Tire Order Code: - TBD -
• Rear Tire Order Code: - TBD -
• Spare Tire Order Code: - TBD -
• Front Tire Size: LT245/75R16
• Rear Tire Size: LT245/75R16
• Spare Tire Size: LT245/75R16
• Wheels
• Front Wheel Size (in): 16 x 8
• Rear Wheel Size (in): 16 x 8
• Spare Wheel Size (in): 16 x 8
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Aluminum
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), Overall: - TBD -
• Lock to Lock Turns (Steering): - TBD -
• Turning Diameter - Curb to Curb (ft): 35.8
• Turning Diameter - Wall to Wall (ft): - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 19
• Exterior Dimensions
• Wheelbase (in): 93.4
• Length, Overall (in): 155.4
• Width, Max w/o mirrors (in): 66.7
• Height, Overall (in): 70.9
• Track Width, Front (in): 58.0
• Track Width, Rear (in): 58.0
• Min Ground Clearance (in): 8.2
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Liftover Height (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): - TBD -
• Cargo Area Length @ Floor to Seat 2 (in): - TBD -
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): 42.7
• Cargo Volume to Seat 2 (ft³): 9.1
• Interior Dimensions
• Passenger Capacity: 4
• Passenger Volume (ft³): 93.8
• Front Head Room (in): 41.9
• Front Leg Room (in): 41.1
• Front Shoulder Room (in): 50.8
• Front Hip Room (in): 51.8
• Second Head Room (in): 40.9
• Second Leg Room (in): 35.0
• Second Shoulder Room (in): 57.3
• Second Hip Room (in): 43.5
• Summary
• Vehicle Name: Jeep Wrangler
• Body Style: 4 Door
